Supermicro Partner

Supermicro

Supermicro's MegaDC series delivers top performance per dollar and per watt across various sectors, with optimized component integration for cost-effectiveness and versatility, enabling quick deployment for diverse workloads.

The latest MegaDC servers, powered by AmpereOne® CPUs with up to 192 cores, set new standards in energy efficiency, performance, and flexibility. These servers excel in AI inference tasks and advanced data management at scale, thanks to the AmpereOne processors.

Offering configurations from 32 to 192 cores per CPU socket, the MegaDC series is optimized for accelerating cloud-native application stacks. It provides predictable performance by mitigating issues like noisy neighbors, allowing customers to increase infrastructure load without performance losses from Simultaneous Multi-Threading (SMT).

AI Inference Servers

ARS-112M-NR

<table class="markdownTable"> <thead> <tr> <td>Height</td> <td>1U</td> </tr> <tr> <td>CPU</td> <td>1 x AmpereOne M (up to 192)</td> </tr> <tr> <td>Memory</td> <td>12 DIMM slots/12 Channel<br> Max Memory (1DPC): 1.5TB 5600MT/s ECC DDR5 RDIMM/LRDIMM </td> </tr> <tr> <td>Storage</td> <td>12 front hot-swap 2.5” PCle 5.0 x 4 NVMe/SAS*/SATA* drive bays (* May require additional storage controller and/or cables)</td> </tr> <tr> <td>Network</td> <td>1 RJ45 1GbE Dedicated BMC LAN Port<br> 1 RJ45 10 GbE LAN Port </td> </tr> <tr> <td>PCIE</td> <td> - 1 PCIe 5.0 x 16 FHFL double-width slot<br> - 1 PCle 5.0 x 8 FHHL slot<br> - 1 PCle 5.0 x 16 AIOM slot (OCP 3.0 compatible)<br> - 1 PCle 5.0 x 16 FHFL slot </td> </tr> </tbody> </table>

<center>ARS-211M-NR</center>

<table class="markdownTable"> <thead> <tr> <td>Height</td> <td>2U</td> </tr> <tr> <td>CPU</td> <td>1 x AmpereOne (Up to 192)</td> </tr> <tr> <td>Memory</td> <td>16 DIMMs DDR5-4800 (8-channels, 2DPC) Up to 4TB</td> </tr> <tr> <td>Storage</td> <td> 4 hot-swap 2.5" U.2 NVMe <br> (Option for 16 or 24 NVMe) </td> </tr> <tr> <td>Network</td> <td>2 x 2.5Gb LAN SPF28 Ports via BCM57414 controller w/NC-SI</td> </tr> <tr> <td>PCIE</td> <td> - 4 PCIe 5.0 x 16 FHFL <br> - 1 PCIe 5.0 x 16 LP slot <br> - 1 PCIe 5.0 x 16 AIOM slot (OCP 3.0 compatible) </td> </tr> </tbody> </table>

<center>ARS-211ME-FNR</center>

<table class="markdownTable"> <thead> <tr> <td>Height</td> <td>2U</td> </tr> <tr> <td>CPU</td> <td>1 x AmpereOne (Up to 192)</td> </tr> <tr> <td>Memory</td> <td>16 DIMMs DDR5-4800 (8-channels, 2DPC) Up to 4TB</td> </tr> <tr> <td>Storage</td> <td>6 hot-swap 2.5" U.2 NVMe</td> </tr> <tr> <td>Network</td> <td>2 x 2.5Gb LAN SPF28 Ports via BCM57414 controller w/NC-SI</td> </tr> <tr> <td>PCIE</td> <td> - 2 PCle 5.0 x 8, FHFL slots <br> - 2 PCIe 5.0 x 16 FHFL slots <br> - 1 PCIe 5.0 x 16 LP slot <br> - 1 PCIe 5.0 x 16 AIOM slot (OCP 3.0 compatible)</td> </tr> </tbody> </table>

<center>ARS-111M-NR</center>

<table class="markdownTable"> <thead> <tr> <td>Height</td> <td>1U</td> </tr> <tr> <td>CPU</td> <td>1 x AmpereOne (Up to 192)</td> </tr> <tr> <td>Memory</td> <td>16 DIMMs DDR5-4800 (8-channels, 2DPC) Up to 4TB</td> </tr> <tr> <td>Storage</td> <td>10 hot-swap 2.5" U.2 NVMe</td> </tr> <tr> <td>Network</td> <td>2 x 2.5Gb LAN SPF28 Ports via BCM57414 controller w/NC-SI</td> </tr> <tr> <td>PCIE</td> <td> - 3 PCIe 5.0 x 16 LP slots <br> - 1 PCIe 5.0 x 16 AIOM slot (OCP 3.0 compatible)</td> </tr> </tbody> </table>

<center>ARS-520M-NRL</center>

<table class="markdownTable"> <thead> <tr> <td>Height</td> <td>2U</td> </tr> <tr> <td>CPU</td> <td>1X Altra Q80-30 , 1X Altra Max M128-30</td> </tr> <tr> <td>Memory</td> <td>DDR4- 3200MT/s</td> </tr> <tr> <td>Storage</td> <td>4 front hot-swap 3.5"/2.5" NVMe/SAS/SATA <br> 8 front hot-swap 3.5"/2.5" SAS/SATA </td> </tr> <tr> <td>Network</td> <td>Dual SFP28 25GbE</td> </tr> <tr> <td>PCIE</td> <td> - 3 PCIe 4.0 x16 LP slots<br> - 1 PCIe 4.0 x16 AIOM slot (OCP 3.0 compatible) </td> </tr> </tbody> </table>

ARS-110M-NR

<center>ARS-110M-NR</center>

**Form Factor:** 1U <br> **CPU:** 1 x Altra Max M128-30<br> **Memory:** 128GB DDR4 3200MT/s <br> **Storage:** 1 x 1TB M.2, 1 x 1.92TB NVMe <br> **Network:** Dual 25GbE Onboard <br> **PCIE:** 3 x HHHL PCIe Gen 4.0 x 16 1 x OCP 3.0 (AIOM)

ARS-210M-NR

<Center>ARS-210M-NR</center>

**Form Factor:** 2U <br> **CPU:** 1 x Altra Max M128-30<br> **Memory:** 128GB DDR4 3200MT/s <br> **Storage:** 960GB M.2 and 1.9TB NVMe <br> **Max GPU:** Up to 4 double-width GPU(s) <br> **Network:** Dual 25GbE Onboard <br> **PCIE:** 4 x DW FHFL PCIe Gen 4.0 x 16 <br> 1 x HHHL PCIe Gen 4.0 x 16 1 x OCP 3.0 (AIOM)

ARS-210ME-FNR

<center>ARS-210ME-FNR</center>

**Form Factor:** 2U Short Depth<br> **CPU:** 1x Altra Q80-30<br> **Memory:** 256GB DDR4 3200MT/s <br> **Storage:** 960GB M.2 and 1.9TB NVMe <br> **Network:** Dual 25GbE Onboard <br> **PCIE:** 4xFHHL, 1 x HHHL PCle 4.0 <br> 1 x OCP 3.0 (AIOM)
